TC Type=1x S;

Accuracy=class 1;
Design=Wire diameter 0.50mm

Sensor range=-50..+1768 °C

Insertion Length (He)=780 mm

Pipe Diameter (Dg)=22x19.40 mm;

Material=Kanthal AF;
Max. Temp.=1300 °C/Lg max=1000
mm

Immersion Length (Lg)=700
mm

Internal Protective Sheath=Ceramic
sheath C799; Diameter=6x4 mm

Terminal
Type=Terminal block DIN B

Process
Connection=71214289; Sliding flange ANSI
2" 150lbs RF

, Alloy 600 with compression
fitting GCP welded on flange for pipe
OD21.3..22

Head=TA30D Alu, high cover,
IP66/68; Cable Entry=M20

Without Head
Transmitter
